Description
General specifications
| Product Name |
Eaton Arrow Hart power device receptacle
|
| Catalog Number |
AH1257BK-F
|
| UPC |
032664006364
|
| Product Length/Depth |
2.112 in
|
| Product Height |
3.688 in
|
| Product Width |
2.455 in
|
| Product Weight |
0.35 lb
|
| Certifications | UL 498 C22.2 |
Product specifications
| Features |
Dryer receptacle
|
| Special features |
Dryer receptacle
|
| Type |
Flush mount receptacle
|
| Amperage Rating |
30A
|
| Voltage rating |
125/250V
|
| Wiring method |
Back
|
| Number of wires |
4
|
| Mounting method |
Flush
|
| Number of poles |
Three-pole
|
| Color |
Black
|
| Connection type |
Screw
|
| Style |
Power
|
| NEMA configuration |
14-30R
|
| Base color |
Black
|
| Design type |
Receptacle
|
| Receptacle type |
Three-pole, four-wire, grounding
|
