Description

• Provides SuperSpeed USB 3.0 (5 Gbps) link between computer to video, audio, network, and two additional USB 3.0 ports.
• Compatible with Windows 10, 8.1, 8, 7, Vista, and mac OS 10.2 or above.
• Backwards compatible with USB 2.0 (480Mbps) for both the PC and attached devices.
• HDMI and DVI/VGA ports for two external monitors supports display resolutions up to 2560×1440* (single HDMI) and DVI / VGA to 2048×1152 / 1920×1200.
• Network port offers wired 10/100/1000 Gigabit Ethernet connectivity. Graphics, audio, and networking all managed by single DisplayLink DL-3900 chipset.
• Stereo audio in/out with hotplug detection.

• TECHNICAL SPECIFICATIONS
• Model

  UG39DK1 (Black)

• Ports

  4 x USB-A 2.0

  2 x USB-A 3.0

  1 x USB-B

  1 x DC Power Input Port

  1 x Microphone Input Port

  1 x Audio Output Port

  1 x HDMI

  1 x DVI or VGA (through converter)

  1 x RJ45 Gigabit Ethernet

• LED

  Blue

• Power Supply

  DC12V / 2A

• DIMENSIONS
• Unit Dimensions

  225mm x 88mm x 27mm ( L x W x H )

• Housing Material

  ABS

• Shell Color

  Black

• FUNCTIONS
• Working Standards

  USB 3.0 5Gbps

  HDMI DVI Video

  Microphone/Earphone Input/Output

  USB 3.0 to Gigabit

  VGA (DVI to VGA Adapter)

• Operating System Support

  Windows 10/8.1/8/7/Vista

  Mac OS 10.2 and above

• PACKAGE In The Box

  1 x USB 3.0 Docking Station

  1 x SuperSpeed USB 3.0 Cable

  1 x DVI convert to VGA Adapter

  1 x DC12V/2A Certified Power Adapter

  1 x User Manual
